NL BEARINGS

Models available:

• NU, NJ, NUP and N design, single row cylindrical roller bearings, caged
• NNU and NN design, double row cylindrical roller bearings, caged
• Multi-row cylindrical roller bearings, caged.
• NCF and NJG design, single row full complement cylindrical roller bearings
• NNF design, double row full complement cylindrical roller bearings
• Multi-row full complement cylindrical roller bearings, with four or eight rows of rollers.

Application :
Middle and large-sized motors, locomotives, machine tool spindles, internal combustion engines, electricity generators, gas turbines, deceleration devices, rolling mills and other industrial machines.

Detailed Description:

• Series: 3200, 3300, 5200, 5300, 7000,7200,7300,7900
• Type: A, B, C, DB, DF, DT
• Cage: nylon or steel
• Material: GCr15SiMn
• Single Row angular Contact Ball Bearing and Double Row angular Contact Ball Bearing
• Angular contact ball bearings have raceways in the inner and outer rings that are displaced with respect to each other in the direction of the bearing axis.
• This means that they are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.
• The axial load carrying capacity of angular contact ball bearings increases with increasing contact angle. The contact angle α is defined as the angle between the line joining the points of contact of the ball and the raceways in the radial plane, along which the load is transmitted from one raceway to another, and a line perpendicular to the bearing axis

Detailed Description:

• Series: 6000,6200,6300,6400,6700,6800,6900, 16 000.
• Model Open, Z, ZZ, RZ, 2RZ, RS, 2RS
• Quality accords with the Industry Standards
• Types: Single Row DGBB, Double Row DGBB, Stainless DGBB, DGBB with filling slots, Stainless Steel Single Row DGBB, Single Row Hybrid DGBB, Sing Row DGBB for High Temperature, Ploymer Ball Bearings and so on
• Bearing is non-separable.

Application :
Bowling pinsetters, electric motors, elevators, fork lift trucks, paper converting, power tools, printing machinery, pumps, textile machinery, woodworking and so on.

Detailed Description:

Series:60,62,63,68,69,MR, F60、F62、F68、F69、MF
Metric Series
Open: Bore sizes 1 mm to 9 mm
Shielded: Bore sizes 1 mm to 10 mm
Flanged:Bore sizes 2 mm to 12 mm
Inch Series
Open:Bore sizes 0.0781 to 0.375 inches
Shielded:Bore sizes 0.0781 to 0.375 inches
Flanged:Bore sizes 0.0781 to 0.375 inches
Unflanged Extended Inner 0.0469 to 0.3125 inches
Flanged Extended Inner 0.0469 to 0.3125 inches

Application :
Micro-motors, fitness equipment, telecommunications equipment, instrumentation, computers, automotive motors, precision instruments, mechanical equipment, household appliances, medical equipment, fishing gear, remote control toys, fans, pulleys

Detailed Description:

Series:
22 200,22300,22 400,23000,23 100,
23 200,23900,24 000,24100.
Cage: Steel or Brass. CA or MB. or CC
Spherical roller bearings are principally provided with two rows of symmetrical spherical rollers and a common sphere raceway in out ring, the two inner ring raceways are included at an angle to the bearing axial. The bearings have good self-aligning ability and can operate when the shaft deflection under load or the shaft deflection under load or the shaft misaligningment in mounting, and their permissible aligning angle is 1 to 2.5 degree. This type of bearings has heavy load carrying capacity and anti-impact ability, in addition to radial loads, they also can carry axial loads in two directions. In general, this type of bearings permit a low limiting speed.

Application:
Automobiles, high-precision machine tool, high-frequency motor, centrifuge, gear spindle, etc.

Detailed Description:

• Series:
• 6000,6200,6300,6400,6700,6800,6900,
• 16 000.
• Model Open, Z, ZZ, RZ, 2RZ, RS, 2RS
• Quality accords with the Industry Standards
• Types: Single Row DGBB, Double Row DGBB, Stainless DGBB, DGBB with filling slots, Stainless Steel Single Row DGBB, Single Row Hybrid DGBB, Sing Row DGBB for High Temperature, Ploymer Ball Bearings and so on
• Bearing is non-separable.

Application :
Bowling pinsetters, electric motors, elevators, fork lift trucks, paper converting, power tools, printing machinery, pumps, textile machinery, woodworking and so on.

Detailed Description:
Series:
GE, GEES2RS, GAC, GEC, GEG, GEZ, GEEM, GET, …

Radial spherical plain bearings have an inner ring with a sphered convex outside diameter and an outer ring with a correspondingly sphered but concave inside surface. Their design makes them particularly suitable for bearing arrangements where alignment movements between shaft and housing have to be accommodated, or where oscillating or recurrent tilting or slewing movements must be permitted at relatively slow sliding speeds.

Detailed Description:

Series：
51 100,51200,51 300,51400,23 900,29400

Thrust ball bearings have two designs: single direction and double direction. The single direction design comprises two rings, referred to as shaft and housing washers and a single ball and cage assembly. The double direction design, on the other hand, comprises three washers and two ball and cage assemblies. The ball and cage assemblies of the double direction type are separated by the shaft washer.

Detailed Description:

Series:
30 200,30300,31 300,32300,33 000.

Tapered roller bearings are generally of separable design and have tapered cone and cup raceway between which tapered roller are arranged, their design makes tapered roller bearings particularly suitable for carrying combined (radial and axial) load.

Application :
Agriculture, Construction and Mining Equipment, Various Axle Systems, Conveyance Vehicles, Gear Box, Engine Motors, Reducers etc.

Detailed Description:

Series: 1200,1300,2200,2300.

The self-aligning ball bearing has two rows of balls and a common concave sphered raceway in the outer ring. The bearing is consequently self-aligning and insensitive to angular misalignments of the shaft relative to the housing. It is particularly suitable for applications where considerable shaft deflections or misalignment are to be expected. Additionally, the self-aligning ball bearing has the lowest friction of all rolling bearings, which enables it to run cooler even at high speeds.

Application :
Widely used in machinery of mining, power, and textile etc.

Detailed Description:

Series:
UC, UCP, UCF, UCT, UCF, SA, SB, CS

Pillow Block consist of the insert ball bearing and house, the inster bearing is the deep groove ball bearings with wide inner rings, it insert in housing work as an unit bearings. The housing are mainly casting or pressed steel. The bearing unit are compact in design with perfect sealing devices, they can align with easy during operation and can be conveniently mounted or dismounted. When mounted in appropriate housings to form housed bearing units, they are able to compensate for initial errors of alignment.

Application :
Agricultural machinery, construction machinery, textile machinery, food processing machinery, conveyor belt systems

Detailed Description:

Series: SE3, SE5,SE7,SE9,SE12,SE14,SE17,SE21.SE25

• Single Row Four Point Contact Ball Slewing Bearings.
• Single Row Crossed Roller Slewing Bearings
• Double Row Ball Slewing Bearings
• Three Row Roller Slewing Bearings
• Thin Section Slewing bearings (Light type)
• Thin Section Slewing Bearings (Flange type)

Application :
Auto industry, Wind power, Tower crane, Marine Machinery, Military industry, Mine Nuclear power industry, Agricultural machinery, Oil plate form, Chemical industry.

Detailed Description:

Raw material

• 20Cr for small and medium size u-joint
• 20CrMnTi for big size universal joint
• Gcr15 for universal joint bearing

Series:GUA, GUM, GUN, GUH, GUIS, GGPL

Car parts cross bearing universal joint relative series

Application :
Heavy truck parts, car parts/ automotive industry, commercial vehicle propeller shafts and other industries

Detailed Description:

Series:
DAC40680037 DAC40680042, 42 450−52 060,89544−52 060
Wheel Bearings are double row angular contact ball bearings. Each wheel hub bearing (wheel bearing) consists of one outer ring, two inner rings, rolling elements and cages.
Front Wheel Bearings, Rear Wheel Bearings
Suitable for Various famous Cars, including European cars, Japanese cars and American cars.
Like Volkswagen, Fiat, Benz, Lancia, Seat, Audi, Renault, BMW, Chrysler
Also for Santana, Ford, Opel, Toyota, Nissan, Honda, Volvo, GM and Hyundai
Customer's specifications are welcome.
